Description
Condensation-curing silicone: Elastic, with high continuous temperature resistance and self-extinguishing according to UL 94-HB.
Special Properties at a Glance
- Condensation- and room temperature-curing
- Cold flexible down to -40 °C
- High continuous temperature resistance up to 180 °C
- Elastic molding material for vibration damping
- Self-extinguishing acc. to UL 94 Class HB
- Repairable (mechanically removable)
Areas of Application
Due to its elastic properties and high continuous temperature resistance, Elan-tron® SK 66V2-68 is primarily used for potting coil ends, winding heads, and components subjected to thermal shock. In addition, the material is highly suitable for vibration damping of shock-sensitive components.
Special Advantage: In its cured state, the silicone can be mechanically removed for repair purposes of the potted component and then easily repotted.
Technical Data
| Mixing Ratio | 100 : 2.5 (Potting compound : Crosslinker) |
|---|---|
| Corresponding Crosslinker | Elan-tron® SH 69V5-68 |
| Heat Resistance | -40 °C to 180 °C |
| Curing Conditions | 6 – 8 hours at room temperature |
| Color of Potting Compound | Beige |
| Color of Crosslinker | Transparent blue |
Available Packaging Sizes
| Component | Article Number | Content |
|---|---|---|
| SK Potting Compound | R SK 66V2-68-5 | 5 kg |
| SK Potting Compound | R SK 66V2-68-25 | 25 kg |
| Crosslinker | R SH 69V5-68-0125 | 0.125 kg |
| Crosslinker | R SH 69V5-68-0625 | 0.625 kg |
