Elan-tron MC 4260 Epoxy Casting System, Thermal Class 180 (H)
The Elan-tron MC 4260 is a high-quality two-component epoxy system specifically developed for potting (encapsulating) electric motors and transformers. It is characterized by its low viscosity and very good impregnation properties, making it ideal for large castings.
Performance and Safety According to UL Standard
- High Thermal Class: Approved for thermal class 180 (H), ensuring excellent heat resistance.
- Optimal Casting Properties: Low viscosity and very good impregnation properties ensure bubble-free and complete encapsulation of components.
- Low Exothermicity: The low exothermicity is ideal for applications requiring large castings.
- UL Approval: Approved according to UL 94 HB (Files E14115 and E116643), guaranteeing the highest safety standards.
- Wide Range of Applications: Perfectly suited for conventional and linear electric motors as well as transformers.
Technical Specifications and Packaging
| Specification | Detail |
|---|---|
| Product Type | Two-component epoxy system |
| Thermal Class | 180 (H) |
| Resin / Hardener Color | Black / Neutral |
| Approvals | UL 94 HB (File E14115, E116643) |
| Properties | Good electrical and mechanical properties |
Available Packaging (Resin R EIP 4260 MC/W):
- 8 kg container
- 20 kg container
Please refer to the product information for the exact mixing ratio.
Downloads and Reliability
For detailed information and processing instructions, please download the PDF product information. Trust in the tested quality of Elantas products, supplied by your partner Seipp. Discover all casting resins.
