PUR-Impregnated Fiberglass Insulating Sleeving: Protection up to 160°C
The PUR-impregnated fiberglass insulating sleeving offers excellent protection for electrically, thermally, and mechanically stressed components. The combination of alkali-free E-glass and high-quality polyurethane impregnation varnish ensures high dielectric strength and flexibility, even after intense thermal stress.
Customer Benefits: Maximum Safety in Critical Applications
This insulating sleeving is the ideal solution for electric motor and transformer construction, as well as machine, plant, and apparatus construction. Your key advantages:
- Thermal Resistance: No cracking or loss of flexibility after several hours of heat treatment at 160°C – for durability under continuous load.
- High Dielectric Strength: With a voltage of 4000 V, the sleeving provides reliable electrical insulation.
- Chemical Resistance: Good resistance to benzene and oils, increasing application safety in contaminated environments.
- Robust Construction: The alkali-free E-glass fabric ensures high mechanical stability and durability.
Technical Data & Construction
The sleeving is impregnated in several precise steps to guarantee the optimal connection between the fabric and the insulation material.
| Feature | Specification | Detail |
|---|---|---|
| Base Material | Alkali-free E-glass fabric | High mechanical and thermal stability. |
| Impregnation | High-quality PUR impregnation varnish | Multi-layer application for optimal dielectric strength. |
| Wall Thickness | 0.45 – 0.8 mm (± 0.15 mm) | Varies depending on inner diameter and required dielectric strength. |
| Max. Temperature | 160°C (No cracking/flexibility after heat treatment) | Safety in thermally stressed components. |
| Dielectric Strength | 4000 V | Reliable protection of conductors. |
Combine this sleeving with our specialized impregnating resins for the complete solidification of your windings.
Quality Assurance & Ordering
Rely on proven Seipp quality for critical insulation applications. This sleeving is an essential component for the longevity of your electrical components.
